Ql120-349mm Drilling Button Bits Rock Drilling Equipment Tools Dth

  • 1
  • 2
  • 3

Brand Name : MIROC

Model Number : QL120-349mm Dth Button Bits

Certification : ISO

Place of Origin : China

MOQ : 1

Price : negotiation

Payment Terms : T/T or L/C

Supply Ability : 20000 pieces per month

Delivery Time : 25 days

Packaging Details : Carton Box or Wooden Box

Applicable Industries : Energy & Mining

Product name : DTH Bits

Material : High Alloy Steel

Key words : Rock Drilling Tool

Advantage : High Performance

Button shape : Ballistic Spherical Shapes Buttons

Contact Now

QL120-349mm Rock Drilling Equipment Tools Dth Drilling Button Bits

Description

In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.

DTH bits are paired with their corresponding hammers (by drilling hole diameter and spline configuration). Customers can customize their DTH bits in various ways, such as changing the tungsten carbide insert profile (spherical, ballistic, etc.), face profile (flat face, concave, convex, etc.), and flushing holes.

Product: DTH Hammer Bits
Color: Green, Gold, Black or based on customer requirements.
Series: COP/ SD/ DHD/ IR/ Mission/ QL/ BR/ CIR etc
Face: Flat Face, Concave Face, Convex Face, DGR face
Material: High quality carbide and High quality carbon steel
Drill rock type Granite, Marble, Limestone, Basalt, ect.
Project types Blast holes,/Quarry/Anchoring/Infrastructure/Geothermal holesWell drilling,ect.


Applications

• Underground mining
• Quarry benching operations
• Water well drilling

Competitive Advantage

• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment

Specification

Bit Dia.(mm)

Qty.× Button Dia.(mm)

Qty.Air Holes

Weight (kg)

Outer

Front

Back

310

15×19

9×19+10×19+9×16

12×12

3

140

315

18×18

9×18+15×18+9×16

9×16

3

145

320

18×18

9×18+15×18+9×16

9×16

3

150

333

18×19

9×18+15×18+14×16

6×12+6×16

3

155

350

15×19

9×19+15×19+15×16

12×12

3

170

381

18×18

12×18+18×18+21×16

9×14

3

190

400

18×19

12×19+18×19+29×16

12×12

3

230

420

18×19

12×19+18×19+30×16

12×12

3

235


Ql120-349mm Drilling Button Bits Rock Drilling Equipment Tools DthQl120-349mm Drilling Button Bits Rock Drilling Equipment Tools DthQl120-349mm Drilling Button Bits Rock Drilling Equipment Tools DthQl120-349mm Drilling Button Bits Rock Drilling Equipment Tools DthQl120-349mm Drilling Button Bits Rock Drilling Equipment Tools Dth
